ASCO SC8210G022 24V DC BRASS SOLENOID VALVE NORMALLY CLOSED, PIPE SIZE 1 1/2 in.
ASCO SC8210G022 24V DC BRASS SOLENOID VALVE NORMALLY CLOSED, PIPE SIZE 1 1/2 in.
Couldn't load pickup availability
ASCO SC8210G022 24V DC BRASS SOLENOID VALVE NORMALLY CLOSED, PIPE SIZE 1 1/2 in.
Our items are industrial surplus. Original packaging may have shelf wear or be damaged. The item itself will be new and unused.
- Pipe Size - Valves: 1 1/2 in
- Center Line Pipe Center Size: 4 3/16 in
- Electrical Connections: DIN
- Valve Design: 2-Way, 2-Position
- Voltage: 24V DC
- Orifice Diameter: 1 1/4 in
- Valve Configuration: Normally Closed
- Body Material: Brass
- Seal Material: NBR
- Max. Operating Pressure Differential Light Oil: 125 psi
- Max. Operating Pressure Differential Air/Inert Gas: 125 psi
- Max. Operating Pressure Differential Water: 250 psi
- Media: Air, Inert Gases, Water, Light Oil, Other Non-Corrosive Media
- Coefficient of Volume: 22.5
- Overall Width: 3 15/16 in
- Overall Height: 6 1/8 in
- Overall Length: 4 7/16 in
- Coil Insulation Class: F
- Applications: Air Compressors, Car Wash, Industrial Water Control, Laundry Equipment, Pumps
- Max. Fluid Temperature: 150 Degrees F
- Watts: 11.6 W
- Seal Material - Valves: NBR
- IP Rating: 66
