ARM ELECTRONICS C653BC2EIRW ENHANCE IT3 WIDE DYNAMIC 150' IR RANGE
BULLET CAMERA
Our items are industrial surplus. Original packaging may have shelf wear or be damaged. The item itself will be new and unused.
SPECIFICATIONS:
- Image Pick-up Device: 1/3" Sony SuperHad II CCD
- Lens: True D/N auto iris 2.8-12mm
- Total Pixels: 811 (H) x 508 (V), Effective Pixels: 768 (H) x 494 (V)
- Scanning System: 2:1 Interlaced
- OSD: Built-in joystick controlled (on camera board)
- Backlight: Off / HSBLC / BLC selectable
- TV System / Resolution: NTSC / 650 TVL
- S/N (Y Signal): 52 dB (AGC Off, weight on)
- Sense-up: x256
- Minimum Illumination: 0.01 Lux, Sense-up: 0.00006 Lux
- White Balance: ATW / AWB / manual / AWC >SET
- Electronic Shutter Speed: Auto (1/60 to 1/100,000 sec)
- Gain Control: High, Middle, Low, Off
- 3 DNR: 3D-DNR (1 to 50 level adjustable)
- D-WDR: Indoor / Outdoor / Off
- Motion Detection: On / Off (4 zone, alarm output)
- Sharpness: 0 to 31 (level adjustable)
- D&N Selection: Color / BW / Auto / EXT
- Digital Zoom: On (2 to 32X) / Off
- Blemish Compensation: Auto: 128 point, Manual: 4 point
- IR LED: 42pc
- IR LED Range: 150' (27.4 m)
- Power: Dual power (24 VAC / 12 VDC)
- Power Consumption: 120 mA, IR LED on: 250 mA maximum
- Operating Temperature: -20 to 122 °F (-29 to 50 °C), RH 95% maximum
- Weatherproof Rating: IP66
- Dimensions /Weight: 3.4" x 3.8" x 9.9" (86 x 97 x 251 mm) / 3.3 Lb (1.5 kg)
© Energy Power Systems LLC. 2021 - 2022
